Moisture and Temperature in Oil Transmitter Series MMT330
(For Hydraulic and Lubrication Systems and Transformer Oil Monitoring)
Vaisala HUMICAP Moisture and Temperature Transmitter MMT330 series enables fast and reliable detection of moisture in oil in central lubrication systems, hydraulic systems and power transformers. Three probe options offer solutions for various installation requirements, like high pressure, tight spaces and pipeline installations. The series is complient with DNV GL 2.4 type approval (Class B).
TECHNICIAL SPECIFICATIONS
| Output: | 0...1V ; 0...5V; 0...10V; 0...20mA; 4...20mA |
| Operating Voltage: | 10...35VDC, 24VAC ±20% |
| Operating Voltage with optional Power supply module: | 100...240VAC 50/60Hz |
| Measurement Range aw: | 0...1 |
| Accuracy : | ±0.02 |
| Measurement Range T: | -40...+180°C (-40...+356°F) |
| Accuracy : | ±0.2°C |
| IP Rating: | IP66 (IP rating with local display: IP65) |
APPLICATIONS
Applications
Detaylar
