Humidity and Temperature Probe HMP3
(for general purpose humidity and temperature applications with exchangeable sensor)
VAISALA HUMICAP Humidity and Temperature Probe HMP3 is a general-purpose probe designed for processes with moderate humidity and temperature levels. The probe structure allows the sensor to be replaced in the field without tools, making it suitable for applications such as industrial HVAC systems, paint booths, cleanrooms, environmental chambers, and applications where periodic recalibration is not sufficient for maintenance.
TECHICAL SPECIFICATIONS
| Output (digital): | RS485, non isolated |
| Operating Voltage: | 15...30VDC |
| Measurement Range RH: | 0...100%RH |
| Accuracy (at +23°C, between 0...90%RH) : | ±0.8%RH |
| Measurement Range T : | −40 … +120 °C (−40 … +248 °F) |
| Accuracy (At +23°C): | ±0.1°C (±0.18°F) |
| IP Rating: | IP66 |
APPLICATIONS
